Sizes
Diameter: 78mm
Height: 29.8mm
Edge thickness: 4mm
Angle: 125*80°
Special features
Eff: 147.9 lm/W
Material: Borosilicate glass
gt-78-17
Downloads
This product is used for the high-baylighting and other purpose with the 10W~50W integrated chip.
Special features
Eff: 147.98 lm/W
Material: Borosilicate glass
Sizes
Diameter: 78mm
Height: 44mm
Edge thickness: 4mm
Angle: 45°
gt-78-31
Downloads
This product is used for the high-baylighting and other purpose with the 30W~100W integrated chip.
Sizes
Diameter: 78mm
Height: 44mm
Edge thickness: 4mm
Angle: 30°
Special features
Eff: 134.16 lm/W
Material: Borosilicate glass
This product is used for the high-baylighting and other purpose with the 30W~100W integrated chip.
gt-78-52
Downloads
Special features
Eff: 119.01 lm/W
Material: Borosilicate glass
Downloads
gt-78-60
Sizes
Diameter: 78mm
Height: 25.5mm
Edge thickness: 4.2mm
Angle: 100*57°
This product is used for the high-baylighting and other purpose with the 10W~50W integrated chip.
gt-78-65
Special features
Working temp: -50-450℃
Material: Borosilicate glass
This product is used for the high-baylighting and other purpose with the 30W~100W integrated chip.
Sizes
Diameter: 78mm
Height: 40mm
Edge thickness: 4mm
FWHM: 23°
Downloads
In Application
JS lignting achieves customers/creates value/adds color to the world
Individual Beam for your choose
With our "Jinshun individual" service we offer you extensive options for the individualism of series products as well as support in the development of sophisticated special luminaries. In order to match Beam even more efficiently to your project requirements, further variants are available on request in addition to the series configuration. These include,for example:
√ High-power LEDs: 3000K/4000K/5000K/RGBW with CRI 90
√ Housing: Standard color or Custom color
